Aquafine CSL-4R, UV Sterilizer 40 GPM
CSL-4R
Ultraviolet
Aquafine CSL-4R, UV Sterilizer 40 GPM, Aquafine UV Sterilizer 40 GPM, Aquafine UV, Aquafine Ultraviolet, Aquafine, CSL-4R UV, UV Water Sterilizer 40 GPM, Ultraviolet, Ultraviolet Water Sterilizer

Aquafine CSL-4R, UV Sterilizer 40 GPM

Pastikan produk yang anda dapatkan adalah asli dari PFI Watermaker dengan price harga dan kualitas terbaik di Indonesia



·         Disinfection Model: CSL-4R

·         Fresh Water Flow Range (GPM): 40

·         RO/DI Flow Range (GPM): 50

·         Pipe Size: 2"

·         Dimensions L x H X W: 41" x 20-3/4" x 11-1/2"

·         Weight (lbs): 105

·         Total Amps.: 2.2

·         Total Watts: 276

Standard Features:

·         99% Plus Bacterial Reduction

·         Operating Pressure - 120 psig

·         Chamber - 316 Stainless Steel

·         Chamber - Passivated and Electropolished

·         Integral Ballast Enclosure: 304 Stainless Steel

·         LED UV Lamp Operating Display Panel

·         Running Time Meter: 99,999 Hours. - Non resettable

·         Socket Lok™

Mating flanges are NOT supplied with units.
Standard water temperature range 35 degrees F to 100 degrees F (2 degrees C to 38 degrees C)
Socket Lok™ is a registerd trademark of Aquafine Corporation.


Optional Features :

·         S-254 UV Optical Sensor

·         T-120 Temperature Safety Control

·         High Water Temperature Models

·         High Pressure Models (to 150 PSIG)

·         Sanitary Fittings

·         Lamp Out Alert

·         Monitoring Package (see details below)

Optional Monitoring Package Details:

An integrated NIST traceable (optional) UV and temperature monitoring system will accurately monitor UV intensity and process water temperature of your existing UV treatment equipment from Aquafine. The new design improves reliability and performance accuracy in one state-of-the-art monitoring technology system. Component cost savings and improved liability protection will be some of the key benefits you will have with this state-of-the-art monitoring system. The detector employs a Gallium Nitride (GaN) photodiode and a semiconductor temperature sensor in a single package, along with its on-board electronics for remote and local operation features:

·         Detector: UV and temperature sensors in a single housing

·         Optional NIST-traceable UV sensor calibration with certificate upon request

·         No optical filters, no degradation

·         Withstands non-operating temperatures of 250°F

·         121°C for steam sterilization at a maximum pressure of 250psi (17.2 bar)

·         Complete on-board electronics for UV and temperature

·         Absolute and percent UV readout options

·         Detector Cable: Water-resistant axial connector and cabling

·         No diffuser, therefore no UV solarization

·         Temperature sensor and controller does not calibration

·         Detector can be used for UV Monitoring Station and Aqualogic 2000™ system.





Untuk permintaan penawaran silahkan hubungi



PT PROFILTER INDONESIA

Ruko Blok G/54 – Gudang A/01

Jl.Canadian Broadway

Kawasan Pergudangan Commpark – Kotawisata – Cibubur

Mobile : 081385066789

Email : sales@profilterindonesia.com
