Filmtec SW30HRLE-400
Filmtec Membrane
Filmtec SW30HRLE-400, Filmtec, SW30HRLE-400, Filmtec SW30HR LE-400

Filmtec SW30HRLE-400


FilmTec™ offers various premium seawater reverse osmosis (RO) elements designed to reduce capital and operation cost of seawater RO systems. FILMTEC™ products combine premium membrane performance with automated precision fabrication and maximize system output to unprecedented performance.

FILMTEC SW30HR LE-400 element (named FILMTEC SW30HR LE-380 until June 2004) offers very high productivity and rejection, enabling the lowest total cost of water for seawater desalination. Benefits of FILMTEC SW30HR LE-400 :

Enables systems to be designed and operated to optimize operating cost through lower energy consumption or to optimize capital cost through higher productivity at lower operating fluxes. Highest NaCl and boron rejection to help meet World Health Organization (WHO) and other drinking water standards. Can effectively be used in permeate staged seawater desalination systems without impairing the performance of the downstream stage. High performance over the operating lifetime without the use of oxidative post-treatments many competitive products. This is one reason FILMTEC elements are more durable and may be cleaned more effectively over a wider pH range (1-13) than other RO elements. Automated, precision fabrication with a greater number of shorter membrane leaves reduces the effect of overall fouling and maximizes element efficiency, lowering your cost of operation.

Product Data :

Model : SW30HRLE-400

Hard fiberglass outer shell

Diameter : 8.0"

Length : 40"

Applied Pressure : 800PSI

Nominal Capacity in GPD : 7500

Maximum Pressure : 1200PSI

Weight : 40lbs

Stabilized salt rejection : 99.75%

Stabilized boron rejection : 91%

Maximum Operating Temperature : 113F (45C)

Maxium Feed Flow Rate : 85GPM

Maxium Pressure Drop : 15PSI

400 ft2 of active membrane surface area

FilmTec's superior automated manufacturing technology results in the most consistent performance element-to-element and year-after-year

May be cleaned over the widest pH range (pH 1 - 12) for the most effective cleaning
