Filter Bag 1 micron
FB-1
PFI Filter Bag
Filter Bag 1 micron, Filter Bag, 1 micron, Filter 1 micron, Filter, Bag 1 micron, Filter micron

Filter Bag 1 micron


Spesifikasi Bag Filter

Model : PESG , PPSG

Material : Polyester , Polypropylene

Material ring : Stainless Steel 304 dan Polypropylene

Ukuran micron : 1

Ukuran Diameter : 7” , 6” dan 4”

Panjang : 32” , 16” , 15” , 9” , 20”



Tersedia berbagai ukuran dan material untuk keperluan industri air dan minyak, dengan micron yang absolute efisiensi lebih besar dari 95%



Filter Bag 1 micron Code Identification



PPSG       Standard single layer polypropylene felt/Single side glazed/Nominal rating, Removal Efficiency>85%

PPEX       Life extended single layer polypropylene felt/Single side glazed/Nominal rating, Removal Efficiency>85%

PPX         Life extended multi layers polypropylene/Special fiber protective layer/Nominal rating, Removal Efficiency>85%

PPXG      Life extended double layers polypropylene felt /Outer side glazed/Nominal rating, Removal Efficiency>95%

PPAB      Polypropylene oil absorb and adsorb material/Alternate with FSI POMF series products/Nominal rating, Removal Efficiency>95%

PPMD     High removal efficiency and excellent oil absorb and adsorb polypropylene multi layers /Absolute rating/Removal  Efficiency>98%

PPD         Special code for customer designation Polypropylene Multi-layers, Every code designed after special analysis of        customer's process And the configuration
APM       Polypropylene multi media/Absolute rating/Removal Efficiency>98%, APM300 alternate with EATON's 100  series     products& APM900 alternate with EATON's  500 series products

APTM     Polypropylene multi media/Absolute rating/Removal Efficiency>98%, APTM300 alternate with 3M's 100  series         products& APTM900 alternate with 3M's 500 series products

BMAX     Polypropylene standard bag insert seamless cores for high removal efficiency and pre-filtration/Nominal rating, Removal Efficiency>95%, Alternate with FSI's MAX series products.

BMOS     Polypropylene Seamless Bags with fiber protective layers outside/Absolute rating/Removal Efficiency>98%,                Alternate with FSI's BOS series products.

PESG       Standard single layer polyester felt /Single side glazed/Nominal rating, Removal Efficiency>85%

PEEX       Life extended single layer polyester felt /Single side glazed/Nominal rating, Removal Efficiency>85%

PEX         Life extended multi layers polyester /Special fiber protective layer/Nominal rating, Removal Efficiency>85%

PEXG       Life extended double layers polypropylene felt /Outer side glazed/Nominal rating, Removal Efficiency>95%

PEB         Batch order single layer polyester felt /Single side glazed/Nominal rating, Removal Efficiency>85%

PED         Special code for customer designation Polyester Multi layers, Every code designed after special analysis of customer's process And the configuration

NLMO    Standard Nylon mesh for painting degree/Absolute rating/Removal Efficiency>95%

NLMP     Standard Nylon 66 mesh for food and pharmaceutical/Absolute rating/Removal Efficiency>95%

NLMB     Standard Nylon mesh/Absolute rating/Removal Efficiency>95%

NMD       Special code for customer designation Nylon mesh Multi layers Every code designed after special analysis of customer's process And the configuration

PEMO     Standard Polyester mesh/Absolute rating/Removal Efficiency>95%

PPMO     Standard Polypropylene mesh/Absolute rating/Removal Efficiency>95%

ACBX      Granular Activated Carbon/Nominal rating, Removal Efficiency>85%



Filter Bag 1 micron
