FSI BFN-11 Bag Filter Housing Single Bag Non-Code P1 Size 7 Inch x 16.5 Inch
BFN11
Housing Bag Filter
FSI BFN-11 Bag Filter Housing Single Bag Non-Code P1 Size 7 Inch x 16.5 Inch, FSI BFN-11 Bag Filter Housing, FSI BFN-11, Bag Filter Housing Single Bag, FSI BFN-11 Single Bag Filter Housing


FSI BFN-11 Bag Filter Housing Single Bag Non-Code P1 Size 7 Inch x 16.5 Inch



Product Description

When you are looking for a cost-effective filter vessel that is both durable and reliable, look to the BFN series vessels from FSI. Although the BFN series vessels do not carry an ASME Code stamp, you can still realize the benefits of an economic filter vessel that is manufactured to the same high standards and engineering expertise that characterizes all FSI vessels. These housings offer standard side-in, bottom-out connections and a single Buna-N gasketed cover. Housings are available in carbon steel, 304SS and 316SS materials and with a variety of NPT and flange connections. See individual products for more information and ordering instructions.



  • Side-in, Bottom-out configuration
  • Buna-N o-ring for lid seal
  • Available in 65 gpm (size P1) or 125 gpm (size P2) flow rates
  • Rated at 150 psi @ 200°F
  • Permanent piping



*304 or 316 stainless steel is recommended for water applications and 316 stainless steel is recommended for high purity water applications. Carbon steel housings are not internally coated and will rust with water usage.

Other configurations are available, please request a quote for other options.
