Karei ADM-05-1016

Pastikan produk yang anda dapatkan adalah asli dari PFI Watermaker dengan price harga dan kualitas terbaik di Indonesia

ABSOLUTE RATED DOUBLE STRUCTURE SILICONE FREE NON WOVEN MELT BLOWN FILTER

DESCRIPTIONS

ADM is a non-woven melt-blown multi-layer type cartridge filter made of FDA approved Silicone-Free Non Foaming Pure Polypropylene material. Suitable for food contact and wide range of process fluid applications.

ADM is the best economical double structure, multiple layers, high purity graded density cartridge filter available in the market with minimum of 2 – 8 times longer life span than conventional depth cartridge filter. Innermost layer of ADM features a higher density ( 1 grade higher on available micron) fixed pore structure of 3 dimensionally thermal bonded fibers. Outermost layer features a graded density non-woven melt-blown fibers to act as a pre-filter.
By filtering larger particles separately at outermost layers, it reduces the load of innermost layer and provides more room for filtrate to flow through. Thus, provides extremely low pressure drop and longer life span of filter.

ADM is thermally bonded without the use of surfactant, binders and adhesives. Thus, provides superior filtration results and eliminates the need for circulation to achieve product clarity.
Thermally imposed tiny grooves provide reinforcement to the media surface, ensure even water distribution, lower pressure drop and prolong life span of filter.
Suitable for high pressure applications due to the building inner core.

Available in absolute micron rating of 0.5, 1, 3, 5, 10, 25, 50, 75, 100 & 150 micron.
Sealed in individual poly bag.
A guarantee quality product ( ISO 9001 certified) .

SPECIFICATIONS

ABSOLUTE MICRON RATING 0.5, 1, 3, 5, 10, 25, 50, 75, 100 & 150 micron

NOMINAL LENGTH

125, 250, 500, 750, 1000, 1250, 1500 mm or 127, 254, 508, 762, 1016, 1270, 1524 mm

Note : Until 60 Inches.

NOMINAL INNER/ OUTER DIAMETER ( ID/ OD)

Standard : 28/ 63 mm
Note : 30mm inner diameter is available upon request.

MEDIA MATERIAL

Melt Blown Micro-Denier & High Density Silicone Free Pure Polypropylene Fibers.

INNER CORE AND END ADAPTOR MATERIAL

Pure Polypropylene

Reinforced Polypropylene With Glass

END STYLE

DOE : Double Opened End
SOE : Single Opened End
S2C : SOE, 222 O-Ring With Closed End
S2F : SOE, 222 O-Ring With Finned End
S6C : SOE, 226 O-Ring With Closed End
S6F : SOE, 226 O-Ring With Finned End

GASKET MATERIAL

PE : PE Foamed Gasket ( Standard)

O-RING MATERIAL ( OPTIONAL)

Standard : EPDM
V : Viton
S : Silicone
T : Teflon
Note: For filter with SOE style only.

OPERATING CONDITIONS MAX. DIFFERENTIAL PRESSURE

2.1 Bar ( 30 PSID) at 60oC
4.8 Bar ( 70 PSID) at 20oC

MAX. OPERATING TEMPERATURE

80oC at 10 PSID

CHANGE OUT DIFFERENTIAL PRESSURE

2.4 Bar ( 35 PSID)
