MCNP100-40N MegaFlow Filter Cartridges
MCNP100-40N
Pleated Filter Cartridge
MCNP100-40N MegaFlow Filter Cartridges, MCNP100-40N, MegaFlow Filter Cartridges, MCNP100-40N Filter Cartridges, Filter Cartridges

MCNP100-40N MegaFlow Filter Cartridges



MCNP100-40N



 DESCRIPTION

ATTRIBUTE VALUE

PRODUCT TYPE

FILTER CARTRIDGE

CONSTRUCTION

PLEATED DEPTH

FILTER MEDIA

POLYPROPYLENE

FILTER RATING

10 MICRON

DIMENSIONS

6" NOMINAL OD, 40" LONG

END CAP CONFIGURATION

LARGE ID INTERNAL O-RING/FLAT CAP WITH HANDLE

SEAL MATERIAL

BUNA-N

END CAP MATERIAL

GLASS FILLED POLYPROPYLENE

CORE MATERIAL

POLYPROPYLENE

SUPPORT/DRAINAGE

POLYPROPYLENE

TYPICAL FLOW RATE

12.8GPM/PSID 175 MAX

TRADE/BRAND NAME

FULFLO MEGABOND PLUS





High Flow Capacity Pleated Filter Cartridges



Parker’s Fulflo MegaFlow filter cartridges provide a cost effective alternative to wound and other 2 1/2 inch OD style filter cartridges in high flow applications such as reverse osmosis pre-filtration and similar applications where nominal efficiency is sufficient. Each MegaFlow cartridge can handle flow rates up to 175 gpm (662 lpm), significantly reducing the number of cartridges required and the housing size. Each 6 inch (152 mm) diameter MegaFlow cartridge has flow capacity equal to 8 standard 2 1/2 inch OD X 40 inch long filter cartridges. Positive O-ring seals and a built in handle make cartridge installation reliable, fast and easy.

MegaFlow cartridges are available in either pleated polypropylene or cellulose media with nominal ratings of 0.5, 1, 5 and 10 micron.



Benefits

·         High flow capacity means fewer cartridges and reduces labor costs to change

·         High flow capacity allows smaller housings and less capital expenditure

·         Built in handle makes change fast, easy and safe

·         O-ring seal assures filtration integrity

·         Choice of polypropylene or cellulose media allows use in both aqueous and non-aqueous fluid applications

·         Thermally bonded polypropylene and phenolic resin bonded cellulose filter media prevent particle bleed through

·         and unloading that commonly occurs with wound cartridges

·         High surface area pleated design provides lower pressure drop and longer service life than other cartridges

·         All materials of construction in polypropylene cartridges comply with FDA regulations per CFR Title 21

·         Horizontal and vertical housings are available for flow rates up to 3,325 gpm (12,586 LPM)



Applications

·         Potable Water

·         Waste Water

·         Reverse Osmosis Pre-Filtration

·         Lubricating Oil

·         Coolants



Parker Fulflo MegaFlow Filter Cartridges

Specifications

·         Materials of Construction:

·         Media: Polypropylene microfiber (P Code); Cellulose with phenolic binder (C Code)

·         Support Layers: Polypropylene (P Code); None (C Code)

·         End caps: Glass Filled Polypropylene

·         O-Rings: Buna-N, EPR, Silicone, Fluoroelastomer



Recommended Operating Conditions:

·         Change Out Differential Pressure: 35 psid (2.4 bar)

·         Maximum Flow Rate: 175 gpm (662 lpm)

·         Maximum Temperature: 200°F (93°C)

·         Maximum Differential Pressure: 150 psid (10 bar)



Nominal Filtration Ratings:

·         (90%) 0.5, 1, 5 and 10 μm



Dimensions:

·         6 in (152 mm) OD, 3.5 in (89 mm) ID,

·         40 in (1016 mm) long



Surface Area:

·         55-60 ft2 (5.1-5.6m2)



PT.PROFILTER INDONESIA Quick Response + 6281385066789 Email : sales@profilterindonesia.com
