PROCON PUMP



PROCON PRODUCTS  has manufactured high quality, dependable pumps for over fifty years. Since 1950 our precision, hand crafted pumps have served as the benchmark for performance and value in the industries we serve.

PROCON provides new pumps to manufacturers and end users for systems that require transferring clean liquids at pressures up to 250 psi and flows up to 11 gallons per minute. Procon Products manufactures six different styles of pumps with flow rates ranging from 15 to 660 gallons per hour. Available in brass or stainless steel configuration.

Procon rotary vane pumps are suitable for a variety of applications, including Carbonated water for soft drink dispensers, Espresso coffee machines, Beer cooling systems, cooling for TIG Welders, Reverse Osmosis systems, ultra-filtration systems, cooling circulation, constant temperature control, atomizing / misting systems, Automated pesticide misting systems, carwash machines, steam cleaning machines, cooling for X-Ray and medical lasers, water purification, boiler feeds, pressure booster pumps, and light hydraulic oils.



PROCON's Series 1 Product Description

PROCON's Series 1 pumps have the protection of an integral inlet strainer. The standard strainer is a 100 mesh wire screen. It traps particles that can cause serious damage to the pump. The strainer is equipped with a removable cap to allow periodic cleaning, every 4 months under normal conditions (more frequently with hard or turbid water). The clamp-on mounting style is shown in the photo; bolt-on mounting is also available.



Specifications

Body Material:

Type 303 stainless steel or brass

Capacity:

15 to 140 GPH

Nominal Speed:

1725 RPM

Typical Horsepower Required:

.25 to .50 HP

Maximum Discharge Pressure:

250 PSI

Rotation (viewed from nameplate):

Clockwise

Dry Weight:

Approximately 2.5 lbs.

Dimensions:

3.56" x 3.49" x 3.86"

Self Priming (water):

6 ft. Maximum Lift

Port Size:

3/8 NPT Inlet and Outlet



PROCON's Series 2 Product Description

PROCON's Series 2 pumps have the same features as the Series1 except they do not have the integral strainer. Series 1, 2 and 3 are available in 11 flow rates: 15, 25, 35, 50, 60, 70, 80, 100, 110, 125 and 140 gallons per hour at 250 psi. Clamp-on mounting style is shown in the photo; bolt-on mounting is also available.



Specifications

Body Material:

Type 303 stainless steel or brass

Capacity:

15 to 140 GPH

Nominal Speed:

1725 RPM

Typical Horsepower Required:

.25 to .50 HP

Maximum Discharge Pressure:

250 PSI

Rotation (viewed from nameplate):

Clockwise

Dry Weight:

Approximately 2.5 lbs.

Dimensions:

3.56" x 3.49" x 3.86"

Self Priming (water):

6 ft. Maximum Lift

Port Size:

3/8 NPT Inlet and Outlet



Popular Model Numbers

112A125F11XX, 10597,102A100F11AA,102A100R11BA, 102A060R11BA, 102A100F11BA, 102A100F31BB, 102A125F11BA, 112A060F11CB, 102A070F31BC, 112A100F11AA, 102A125F11XX, 102A100F11XX, 102A140R11BA, 102A100R11XX, 102L100F11XX, , 102C110F11BB, 102A100R11BB, 102A1



PROCON's Series 3 Product Description

PROCON's Series 3 pumps boast all the unique design features of other PROCON pumps. Because the pump body and all the internal metal parts are made from stainless steel, the Series 3 is well suited for pumping a variety of fluids not suitable with brass. Your PROCON factory representative can advise you on the correct pump for the fluids you intend to use. Clamp-on mounting style is shown in the photo; bolt -on mounting is also available.



Specifications

Body Material:

Type 303 stainless steel or brass

Capacity:

15 to 140 GPH

Nominal Speed:

1725 RPM

Typical Horsepower Required:

.25 to .50 HP

Maximum Discharge Pressure:

250 PSI

Rotation (viewed from nameplate):

Clockwise

Dry Weight:

Approximately 2.5 lbs.

Dimensions:

3.56" x 3.49" x 3.86"

Self Priming (water):

6 ft. Maximum Lift

Port Size:

3/8 NPT Inlet and Outlet



Popular Model Numbers

113A100F31XX, 103B100F31BA, 113E100F31BA, 103A100F31BA, 113A050F31XX, 103A125G31BA, 103A080G32BC, 103A125F31BC, 113A050F34XX, 10615, 113A100F31BA, 103B140F31BB, 10580, 113C100F32XX, 103A100F31BC, 103A080G31XX



PROCON's Series 4 Product Description

PROCON's Series 4 is designed and built to meet your needs for flow rates ranging from 115 to 330 gallons per hour at 250 psi. This PROCON pump maintains all the quality features and construction of our Series 1, 2, & 3 pumps. Clamp-on mounting style is shown in the photo; bolt -on mounting is also available.



Popular Model Numbers

104E265F12XX, 104E330F11XX, 104E265G12BA, 10543, 104B240F11BA, 104R240R12BC, 104E240F11BA, 114B240F11BA, 104E240F11XX, 104B240F11BC, 104L215F11XX, 104B240F11XX, 104E240F11BC, 114E240F11XX, 104E140F11XX, 104B330F11XX, , 104C240F11XX, 104E240F11AA, 104



PROCON's Series 5 Product Description

PROCON's Series 5 is designed and built to meet your needs for flow rates ranging from 115 to 330 gallons per hour at 250 psi. This PROCON pump maintains all the quality features and construction of our Series 1, 2, & 3 pumps. Clamp-on mounting style is shown in the photo; bolt -on mounting is also available.



Popular Model Numbers

105E240F31XX, 105B240F31BC, 105B265F31XX,105B240F32BC, 105B190F31BC, 105E240F31BA, 105B240F31BA, 10613, 105C240F51BD, 10614
